Product Description 40G series are mainly used for the family heating, while RL series are suitable for industrial use, such as low temperature and medium temperature hot boiler, hot wind or steam boiler, oil guiding heating boiler, etc
Power table
Series
Model
Heating value(KW)
Control Means
Oil
Motor Power
Power(W)
Min
Max
40
G20
95
213
Single stage fire
Light oil/Diesel
1ph*230±10%v*50hz
330
TECHNICAL DATA
Thermal power-output
95-213kw - 8-18 kg/h
Fuel
Light oil , ciscosity 4-6 mm2/s at 20c
Electrical supply
Single phase, 230V+- 10% ~ 50Hz
Motor
Run current 1.4A - 2750 rpm - 288 rad/s
Capacitor
5 uf
Ignition transformer
Secondary 8 kv - 16mA
Pump
Pressure 7-15 bar
Absorbed electrical power
0.320kw
Packing & Delivery:
Packaging
Size
49*39.5*38.5
Weight
16.4kgs
Packaging details
The compact size and light-weighted is very easy for the installation and adjustment, and long distance Express shipment. Board case or wooden case package, around 16.4kgs per case, easy for DHL express shipment or LCL sea shipment
Delivery time and Payment term: For sample orders, 2-5 days after receiving payment; for bulk order larger than 10 pieces, 7-15days after receiving initial payment, based on different item size. Western Union&Paypal or T/T in advance for sample orders; For bulk orders, 30% T/T down to start production, while 70% balance before shipment.
